Description
- Field selectable 12VDC or 24VDC operation: Temporal or continuous tone accommodates regulated and non-regulated power source
- Power source compatibility: Terminal blocks support 12 AWG to 18AWG wires for low current remote signaling appliances
- Durable construction: Textured high impact plastic faceplate available in off-white or fire alarm red
- Flush mounting: Allows for unobtrusive installation on walls or ceilings
- Synchronization capability: Use Gentex Synchronization Module GX91/GX93 for synchronized GX93 Series Horn operation
- Certifications: UL/ULC dual listed, complying with NFPA and other code requirements
- Warranty: Covered for three years from the date of purchase
- Sound output: Temporal 3 tone has a lower rated sound pressure level due to the time the horn is off being averaged into the rating
The GX93 Series minihorn is a high quality remote signaling appliance that offers dependable remote annunciation. This remote signal is listed for use with both filtered and unfiltered power. The GX93 Series low current remote signaling appliances meet NFPA and other code requirements. Choose audible alarms or visual alarm. Fire alarm faceplates feature an attractive textured finish and can be flushmounted to a wall or ceiling.The GX93 can be used on the same sync circuit (AVS Series Control Module) as other Gentex signals. The GX93 appliances are UL 464 listed for use with fire protective systems and are warranted for three years from the date of purchase.Notes: The sound output for the temporal 3 tone is rated lower since the time the horn is off is averaged into the sound output rating. While the horn is producing a tone in the temporal 3 mode its sound pressure is the same as the continuous mode.
