S.U.R. & R Tools AI201G Military Ga-As Oscillator Tunnel Diodes USSR 4 pcs

$ 41.88
Pseudo Checkbox Icon
Order within 0 hours and 0 minutes to get between -
Buying Bulk?
Delivery Truck IconTracked Shipping on All Orders Secure Payments
Headphones Icon 24/7 Customer SupportReturn Product Arrow Icon14-Day Returns
Description
  • AI201G Military Ga-As Oscillator Tunnel Diodes USSR 4 pcs


AI201G at 298 K - 18 to 22 mA at 358 K - 16 to 22 mA at 213 K - 16 to 25 mA The ratio of the peak current to the current trough, at least: AI201G - 10 peak voltage, not more than: AI201G - 0.2 Resistance losses, no more than: AI201G at Iobr and = 100 mA - 5 Ohm The total diode capacitance at low current-voltage characteristics for f = 1 10 MHz: AI201G - no more than 10 pF housing capacity, not more than - 0.8 pF Inductance Diode - no more than 1.3 nH Limit operational data Constant forward voltage at: from 213 to 373 K AI201G- 0.45 from 213 to 358 K AI201G- 0.5 - 0.6 V Ambient temperature: AI201G- from 213 to 358 K
